Control Module Mv-3 800545

Part Details:

• Style: MV-3
• Delivery Port Quantity: 2
• Number Of Delivery Port: 2
• Buttons Included: Yes
• Length: 128.52 mm
• Width: 165.10 mm
• Height: 65.28 mm
• Supply Port Thread Size: 1/4-18 NPT inch
• Delivery Port Thread Size: 1/4-18 NPT inch
• Exhaust Port Thread Size: 1/4-18 NPT inch
• Mounting Thread Size: 1/4-20 UNC-2B inch
• Tractor Trip Pressure: 20 to40 psi
• Trailer Trip Pressure: 25 to45 psi
• Trailer Override Pressure: 20 to 30 psi
• Weight: 0.70 kg
• Minimum Operating Temperature: -40 Deg.F
• Maximum Operating Temperature: 200 Deg.F
