Heavy Duty 7-Way Socket & Plug Connector 82-1001

Original price was: $11.44.Current price is: $3.43.

Availability: 9 in stock

🚚 Free Shipping over $39
✓ Premium Quality
🔒 Secure Payments
↻ Money Back Guarantee
SKU: 82-1001
CATEGORY: Plugs, Sockets & Terminals
Description

Heavy Duty 7-Way Socket & Plug Connector

– Big Rig World carries Genuine OEM and Aftermarket parts to repair your vehicle at the lowest prices.

Grote’s Heavy Duty 7-Way Connectors are designed to meet and exceed SAE J560 specifications. Special features include 2 ½” mounting holes, a plated steel cable guard to prevent cable chafing, and the use of a stainless steel spring.
Technical specifications
  • Material: Zinc die-cast
  • Plug / Socket #: 7
  • Standards: SAE J560
  • Pack Quantity: 1
  • Conductor: 7
Features & benefits
  • Die-cast housing for superior corrosion resistance
  • Solid brass pin terminals for best conductivity
  • Meets and exceeds SAE J560 specifications
  • Terminals accept 16-10 gauge wires; 8 gauge ground wire
  • Sloped socket barrel allows for moisture drainage
  • 40 AMP @ 6-28V DC• 2, 1/2″ mounting holes
  • Circuit identification on the back of the socket
  • Female ground pin for (ISO) to prevent improper connection
Current Part#

82-1001

Old Part No.:

82-1001GR0

Part# variations

82-1001 GR0,
82-1001GR0,
GRO 82-1001,
GRO82-1001

Manufacturer

Grote
