Part Details:
- Model 8800
- L12-24V DOT/ECE LED RHT
- Low Beam
- Chrome Bezel
- Heated
- Height: 107.19 mm / 4.22 in
- Width: 167.64 mm / 6.6 in
- Depth: 84.90 mm / 3.34 in
- Outer Lens Material & Color: Hardcoated Polycarbonate Clear
- Housing Material & Color: Die-Cast Aluminum Black
- Bezel Color: Chrome
- Mounting Type: Low-Profile Panel Mount
- Retrofits 1A1 and 2A1 (4In. 1 6In.) sealed beams
- Minimum Operating Temperature: -40 °C / -40 °F
- Maximum Operating Temperature: 65 °C / 149 °F
- Connector or Wiring H4 Connector – AMP (#172615-2)
- Mating Connector LH Terminal – AMP (#172795-1); RH
- Terminal – AMP (#172796-1)
Features:
- Available with a SmartHeat® Heating System that automatically de-ices headlight according to ambient temperature
- Meets proposed National Highway Transportation Safety Administration (NHTSA) guidelines for a 5-Star NCAP-compliant low beam headlight
- Drop-in replacements for typical buckets/panels used in heavy-duty trucks
- Tough, die-cast housing, with added protection from salt spray for efficient thermal management
- Superior condensation management
- Street legal supporting DOT, Transport Canada ECE and Military standards & requirements
