Reman Starter24 V 8200436

Part Details:

• Pitch: 3 mm
• Mounting Flange to End of Case: 357.90 mm
• Mounting Flange to Pinion End at Rest: 46.70 mm
• Model: 39MT
• Rotation Direction: Clockwise
• Bolt Hole Quantity: 3
• Tooth Quantity: 12
• Polarity: Insulated
• Pinion Gear Tooth Quantity: 12
• Over Crank Protection: Yes
• Solenoid Position: 082
• Family: 39MT
• Solenoid Position Angle: 82 deg
• Nose Cone Material: Aluminum
• Re-Clockable Flange: Yes
• Solenoid Attached: Yes
• Nose Cone Type: Open Nose
• Mounting Type: SAE 3
• Housing Material: Steel
• Voltage: 24 V
• System Voltage: 24 V
• Power Rating: 9 kW
