Secondary Transducer – Red 12-26774-002

This red secondary transducer is designed to monitor and transmit pressure data in electrical systems with high accuracy and durability. Built for heavy-duty applications, it operates within a wide temperature range and withstands significant pressure levels, making it ideal for use in demanding vehicle environments.

• Type: Secondary pressure transducer
• Voltage Range: 4.75 to 5.25 VDC
• Temperature Range: -40 to +120°C
• Minimum Burst Pressure: 450 psi
• Proof Pressure: 300 psi
• Length: 46.97 mm
• Hex Size: 23.85 mm
• Thread Size: 1/8-27 NPTF
• Terminal Quantity: 5
• Housing Material: Aluminum
• Color: Rusty Red
