Solenoid Assembly – Normally Closed K073056

Normally closed solenoid used in stacking manifold assemblies to control fluid flow under pressure. Designed for 2-way operation and responsive control within the specified voltage and pressure ranges.

• Operating voltage: 9 to 16 VDC
• Resistance: 19 ohms
• Connector gender: Male
• Connector type: Metri-Pack 150 Series, 2-way sealed
• Working pressure range: 60 to 150 psi
• Temperature range: -40 to 185 °F
• Operation type: Normally closed
• Length: 47.24 mm
• Width: 36.58 mm
• Height: 65.28 mm
• Mounting dimension: 0.44 inch
• Delivery port thread: 1/4 PTC inch
• Supply port 1 thread: 1/4 PTC inch
• Exhaust orifice diameter: 0.07 inch
• Inlet orifice diameter: 0.07 inch
